ALUMINIUM 6061-T6 FRONT/REAR L-SHAPE PIGGY BACK (BUILT-IN PISTON SPRING) ADJUST

ALUMINIUM 6061-T6 FRONT/REAR L-SHAPE PIGGY BACK (BUILT-IN PISTON SPRING) ADJUSTABLE SPRING DAMPERS
TXM12170/LA
Suitabe For TRAXXAS-XMAXX,TRAXXS-1/5 X-MAXX 8S MONSTER TRUCK
Packaging Includes:
Damper-2pcs
Steel Pin 4*26-2pcs
Steel Pin 4*38-2pcs
2.8MM COIL SPRINGS-2pcs
Original Name / Part No:
7761、7761R
Part Location:
Front or rear dampers
Does this product replace a specific part or function?
Yes
Product major function & usage:
Reduce the friction and absorb the pressure during driving so that the car can be more balanced.
Is this part adjustable? If yes … how and why/purpose?
How: Adjust the top spring retainer and red screw at the bottom of negative pressure oil cylinder.
Purpose: To adjust the hardness of the spring damper.
Major advantages of upgrading to this product:
(1) Made with a quality light weight high tensile strength aluminum 6061-T6 powerful use,The original from 2.5mm spring wire diameter is thickened to 2.6mm, and the 2.8mm orange spring can be replaced.
(2) The damper shaft has thickened from 5.2mm to 7.0mm and smoothly polished to avoid bending.
(3) Aluminum body with shock-absorb cap to seal tightly and avoid leaking.
(4) L shape piggy back with built-in piston spring can adjust the rebound force, so the pressure load effect is better.
Suitable Model:
TRAXXAS-1/5 4WD X-MAXX 6S
TRAXXAS-1/5 ELECTRIC 4WD X-MAXX 8S MONSTER TRUCK
